20DC043A0EYNANANE (Allen-Bradley PowerFlex 700S AC Drive): Specification and Application Guide

1. Overview

The 20DC043A0EYNANANE is an AC variable frequency drive (VFD) belonging to the PowerFlex 700S Series under Rockwell Automation (Allen-Bradley). It is designed for use with 3-phase 400 V AC power supplies and primarily serves motor speed regulation and control in industrial settings. Classified as a standard (Ser. D) product, this model features an IP20 protection rating, making it suitable for installation in well-ventilated environments free from corrosive gases.

---

2. Specifications

Specification	Description
Product Model	20DC043A0EYNANANE
Series	PowerFlex 700S
Input Voltage	400 V AC (3-phase)
Input Current	Approximately 37 A (rated)
Output Power	Approximately 20 kW (equivalent to 27 HP)
Protection Rating	IP20 (NEMA Type 1)
Human-Machine Interface (HMI)	Blank cover plate (display screen optional)
Main Control Component	IGBT power module
Overvoltage/Undervoltage Protection	Adjustable bus undervoltage trip
Heat Dissipation Monitoring	Thermistor monitoring with microprocessor over-temperature trip
Start/Stop Time	Power-Ride-Thru: 15 ms (full load); Logic-Ride-Thru: 0.25 s (not running)

---

3. Product Features

• High-Efficiency IGBT Inverter Technology: Enables wide-range speed regulation and reduces energy consumption.
• Adjustable Bus Undervoltage Protection: Adapts to different power supply conditions and enhances system reliability.
• Fast Start/Stop (Power-Ride-Thru): Meets the needs of applications sensitive to instantaneous load changes.
• Modular Design: Facilitates quick on-site installation and later maintenance.
• Standardized Dimensions and Wiring: Compatible with the layout of most industrial cabinets.

---

4. Structure and Components

• Power Input Terminal: 3-phase input terminal blocks equipped with fuse/circuit breaker protection.
• Power Module: IGBT stack array that provides efficient power conversion.
• Heat Dissipation System: Internal heat sinks + optional fan, combined with thermistor monitoring.
• Control Unit: A microprocessor responsible for parameter setting, fault diagnosis, and communication.
• Optional Human-Machine Interface (HMI): LCD/LED display with buttons, or a blank cover plate.
• Enclosure: Metal cabinet with IP20 protection rating, offering mechanical protection.

---

5. Application Fields

• Material handling systems (conveyor belts, elevators)
• Food processing (mixing, packaging equipment)
• Textile machinery (spinning, weaving machines)
• Plastic processing (injection molding, extruders)
• Machine tools (CNC lathes, milling machines)
• Other industrial automation equipment requiring reliable speed regulation.

---

6. Installation and Maintenance

Installation

1. Secure the drive in a well-ventilated cabinet free from corrosive gases.
2. Complete the wiring for 3-phase power, output motor, grounding, and control signals in accordance with the wiring diagram.
3. If a display screen or keypad is used, assemble the corresponding panel as instructed in the manual.

Commissioning

1. Set basic parameters (such as motor rated power and acceleration/deceleration time) via the built-in parameter menu or an external PLC/controller.
2. Check the tightness and phase sequence of all wiring connections, then power on the drive only after confirming no abnormalities.

Maintenance

1. Regularly inspect cooling fans and heat sinks for dust accumulation to maintain effective heat dissipation.
2. Check input/output terminals and wiring terminals for looseness or corrosion.
3. Use the drive’s built-in fault diagnosis function or upper-level system monitoring to handle alarm information promptly.
4. Do not allow non-professionals to disassemble internal power modules, as this may pose safety hazards.

 ------------------------------------------
